Universal X-Ray Inspection System XCT8500

Description

Model : XCT8500

X-ray Tube Type : Reflective Sealed micro-focus X-ray Source

Tube Voltage Range : 25 - 160 Kv

Tube Current Range : 0.01 - 1.0 mA

Maximum Tube Power : 64 W

Maximum Target Power : 10 W

Micro Focus Size : <1 μm

Fiat Panel Type : Amorphous Silicon flat panel Detector

Pixel Matrix : 1536 x 1536

Field of View : 130 x 130 mm

Resolution : 5.8Lp/mm

Image Frame Rate (1 x 1) : 20 fps

AD Conversion Digits : 16 bits

Maximum Sample Size : 750 x 650 mm

Maximum inspection Area : 550 x 550 mm

Image Geomatic Magnification : 2000X

Input Power : 220 V 10A 50-60 HZ

Operation System : DELL Precision T7920 Image Workstation

Dimension : 1600 x 1700 x 2000 mm (L x W x H)

Weight : 2950 KG
