หัวฉีดเครื่องล้างในคลีนรูม Cleaning head for cleaning machines ssbl series

รายละเอียด

หัวฉีดเครื่องล้างในคลีนรูม Cleaning head for cleaning machines ssbl series

Model  SSBL series

Discharge pressure SSBL-20: 0.98 to 9.8 MPa

SSBL-30: 1.47 to 14.7 MPa

SSBL-37.5: 1.76 to 17.6 MPa

Discharge flow rate SSBL-20: 1.13 LPM

SSBL-30: 0.7

LPM SSBL-37.5: 0.58 LPM

Driving air pressur  0.05 to 0.5 MPa

Air consumption  Approximately 70 L (when the number of pump strokes is 60 SPM)

Wetted seal  Pure water, IPA ··· FKM  NMP · · · Kalrez

Product Summary

Available for explosion-proof areas because electricity is not used with air-driven plunger pumps

Ideal for incorporating lift-off devices, etc.

Use

Used for IPA cleaning of wafers and detachment by solvent for high pressure jet cleaning
