SIBATA Digital manometer DM-300S type
Add to Wishlist
Approximately 700g lightweight compact size including batteries Continuous operation for 60 hours or more is possible with two AA batteries.
Availability:
Out of stock
Contact for a quote.
Request for Quotationช่องทางการสั่งซื้ออื่น ๆ
ติดต่อทาง Line
@santatech
ติดต่อทางอีเมล์
santatech@gmail.com
ติดต่อทางโทรศัพท์
02-1013454
Description
| Item Code | 071060-3001 |
|---|---|
| Model | DM-300s |
| Measurement Range | 0 ~ 101.3kpa (absolute pressure) |
| Accuracy | ± 0.35 % of F.S ± 1digit |
| Connection |
Outer diameter φ9mm (screw standard 1/4R) Material SCS14 (equivalent to SUS316) Removable |
| Measured pressure | Absolute pressure |
| Measuring fluid | A gas that does not corrode SUS316 |
| Measurement display | Digital (LED) |
| Minimum value displayed | 0.1kpa |
| Temperature drift | Zero/Span ± 0.2 %/℃ OF F.S |
| Record meter output | 0 to 1V from 0 to 100kpa |
| Mass | 0.7kg |
| Operating Environment | 5-40 ° C |
| Power Supply | AC100V and AA batteries x 2 (100V power supply requires an optional AC adapter) |
| Size | W96 x D77 x H89mm |
