ตู้อบลมร้อน Memmert UF1060plus
Add to Wishlist
Memmert UF1060plus ตู้อบลมร้อน ตู้อบอเนกประสงค์ UF1060plus การอบแห้งความร้อนการชะลอวัยการเผาในและการชุบแข็งอย่างแม่นยำในการวิจัยวิทยาศาสตร์อุตสาหกรรมและการประกันคุณภาพ
Availability:
1 in stock
ติดต่อขอใบเสนอราคา
ขอใบเสนอราคาช่องทางการสั่งซื้ออื่น ๆ
ติดต่อทาง Line @santatech ติดต่อทางอีเมล์ santatech@gmail.com ติดต่อทางโทรศัพท์ 02-1013454รายละเอียด
Memmert UF1060plus ตู้อบลมร้อน
ตู้อบอเนกประสงค์ UF1060plus
การจัดส่งแบบมาตรฐาน Universal Oven
เตาอบในห้องปฏิบัติการ U ที่ใช้งานได้ทั่วไปเป็นอุปกรณ์คลาสสิกของ Memmert สำหรับการควบคุมอุณหภูมิในด้านวิทยาศาสตร์การวิจัยและการทดสอบวัสดุในอุตสาหกรรม ผลงานชิ้นเอกที่สมบูรณ์แบบทางเทคโนโลยีที่ทำจากสแตนเลสสตีลคุณภาพสูงถูกสุขอนามัยทำความสะอาดง่ายไม่เป็นที่ต้องการในแง่ของเทคโนโลยีการระบายอากาศและการควบคุมการป้องกันอุณหภูมิที่สูงเกินไปและเทคโนโลยีการทำความร้อนที่ปรับแต่งอย่างแม่นยำ
ในหน้านี้คุณจะพบข้อมูลทางเทคนิคที่จำเป็นทั้งหมดเกี่ยวกับเตาอบในห้องปฏิบัติการ Memmert สากล ทีมงานลูกค้าสัมพันธ์ของเรายินดีที่จะช่วยเหลือหากคุณต้องการข้อมูลเพิ่มเติม หากคุณต้องการโซลูชันพิเศษที่กำหนดเอง
เตาอบในห้องปฏิบัติการ U ที่ใช้งานได้ทั่วไปเป็นอุปกรณ์คลาสสิกของ Memmert สำหรับการควบคุมอุณหภูมิในด้านวิทยาศาสตร์การวิจัยและการทดสอบวัสดุในอุตสาหกรรม ผลงานชิ้นเอกที่สมบูรณ์แบบทางเทคโนโลยีที่ทำจากสแตนเลสสตีลคุณภาพสูงถูกสุขอนามัยทำความสะอาดง่ายไม่เป็นที่ต้องการในแง่ของเทคโนโลยีการระบายอากาศและการควบคุมการป้องกันอุณหภูมิที่สูงเกินไปและเทคโนโลยีการทำความร้อนที่ปรับแต่งอย่างแม่นยำ
ในหน้านี้คุณจะพบข้อมูลทางเทคนิคที่จำเป็นทั้งหมดเกี่ยวกับเตาอบในห้องปฏิบัติการ Memmert สากล ทีมงานลูกค้าสัมพันธ์ของเรายินดีที่จะช่วยเหลือหากคุณต้องการข้อมูลเพิ่มเติม หากคุณต้องการโซลูชันพิเศษที่กำหนดเอง
Temperature
Working temperature range | at least 5 (UN/UNplus/UNm/UNmplus) or 10 (UF/UFplus/UFm/UFmplus) above ambient temperature to +300 °C |
---|---|
Setting accuracy temperature | up to 99.9 °C: 0.1 / from 100 °C: 0.5 |
Setting temperature range | +20 to +300 °C |
Temperature sensor | 2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring, taking over functions in case of an error |
Control technology
ControlCOCKPIT | TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-colour displays. |
---|---|
Language setting | German, English, Spanish, French, Polish, Czech, Hungarian |
Timer | Digital backwards counter with target time setting, adjustable from 1 minute to 99 days |
Function HeatBALANCE | adapting the distribution of the heating performance of the upper and lower heating circuit from -50 % to +50 % |
Function SetpointWAIT | the process time does not start until the set temperature is reached |
Calibration | three freely selectable temperature values |
adjustable parameters | temperature (Celsius or Fahrenheit), fan speed, air flap position, programme time, time zones, summertime/wintertime |
Ventilation
Fan | forced air circulation by 2 quiet air turbines, adjustable in 10 % steps for each segment individually |
---|---|
Fresh air | Admixture of pre-heated fresh air by electronically adjustable air flap |
Vent | vent connection with restrictor flap |
Communication
Documentation | programme stored in case of power failure |
---|---|
Programming | AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port |
Safety
Temperature control | mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 20°C above nominal temperature |
---|---|
Temperature control | overtemperature monitor TWW, protection class 3.1 or adjustable temperature limiter TWB, protection class 2, selectable on display |
AutoSAFETY | additionally integrated over- and undertemperature monitor "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating is switched off in case of overtemperature |
Autodiagnostic system | for fault analysis |
Alarm | visual and acoustic |
Standard equipment
Internals | 2 stainless steel grid(s), electropolished |
---|---|
Works calibration certificate | Calibration at +160°C |
Door | fully insulated stainless steel doors with 2-point locking (compression door lock) |
Stainless steel interior
Dimensions | w(A) x h(B) x d(C): 1040 x 1200 x 850 mm (d less 39 mm for fan) |
---|---|
Interior | easy-to-clean interior,made of stainless steel, reinforced by deep drawn ribbing with integrated and protected large-area heating on four sides |
Volume | 1060 l |
Max. number of internals | 14 |
Max. loading of chamber | 300 kg |
Max. loading per internal | 20 kg |
Textured stainless steel casing
Dimensions | w(D) x h(E) x d(F): 1224 x 1720 x 1035 mm (d +56mm door handle) |
---|---|
Installation | on lockable castors |
Housing | rear zinc-plated steel |
Electrical data
Voltage Electrical load | 400 V, 3 phases, 50 Hz approx. 7000 W |
---|
Ambient conditions
Set Up | The distance between the wall and the rear of the appliance must be at least 15 cm. The clearance from the ceiling must not be less than 20 cm and the side clearance from walls or nearby appliances must not be less than 5 cm. |
---|---|
Altitude of installation | max. 2,000 m above sea level |
Ambient temperature | +5 °C to +40 °C |
Humidity rh | max. 80 %, non-condensing |
Overvoltage category | II |
Pollution degree | 2 |
Packing/shipping data
Transport information | The appliances must be transported upright |
---|---|
Customs tariff number | 8419 8998 |
Country of origin | Federal Republic of Germany |
WEEE-Reg.-No. | DE 66812464 |
Dimensions approx incl. carton | w x h x d: 1370 x 1970 x 1300 mm |
Net weight | approx. 252 kg |
Gross weight carton | approx. 416 kg |
